Canadian Industrial Design Patent No. 195351 (Face Shield)

National Application/Registration : 195351
Date of Registration : 2021-10-21
Made available on : 2021-10-21
Status : Registered
Title or finished article: FACE SHIELD
Canadian Classification: 29-02-DEVICES AND EQUIPMENT FOR ACCIDENT PREVENTION AND FOR RESCUE, NOT ELSEWHERE SPECIFIED
Description: N/A

Statement: The design is the features of shape and configuration of the FACE SHIELD shown in the representation. The portions shown in broken lines in FIG. 1 illustrating a human figure show environment and do not form part of the design. The application includes a representation of the design in which: FIG.1 is a perspective view of the FACE SHIELD in accordance with said Industrial Design, shown in use; FIG. 2 is a front view of the FACE SHIELD of FIG. 1; FIG. 3 is a left side view of the FACE SHIELD of FIG. 1; FIG. 4 is a top plan view of the FACE SHIELD of FIG. 1; FIG. 5 is a right side view of the FACE SHIELD of FIG. 1; FIG. 6 is a rear view of the FACE SHIELD of FIG. 1; FIG. 7 is a bottom plan view of the FACE SHIELD of FIG. 1; and FIG. 8 is a front view of the guard portion of the FACE SHIELD shown in an unfolded position
